高效节能型硅橡胶线缆连续式智能高温硫化箱
Energy-Efficient Continuous Intelligent High-Temperature Vulcanization Oven for Silicone Rubber Cables
硅橡胶线缆专用高温硫化箱，是硅胶线缆挤出生产线的核心后道配套设备，专为解决传统硫化箱温度不均、能耗高、硫化不充分、无法连续高速生产等行业痛点研发。采用红外加热 + 热风循环双效加热技术，实现 ±1℃全域精准控温，与挤出主机无缝联动同步运行，确保硅胶绝缘层快速均匀硫化，大幅提升线缆耐温等级、绝缘性能与机械强度，是特种硅胶线缆高品质量产的必备核心装备。Special high-temperature vulcanization oven for silicone rubber cables is the core post-processing supporting equipment of silicone cable extrusion production lines, developed to solve industry pain points such as uneven temperature, high energy consumption, insufficient vulcanization and inability to continuous high-speed production of traditional ovens. Adopting infrared heating + hot air circulation dual-effect heating technology, it achieves ±1℃ global precise temperature control, runs synchronously with the extrusion main engine seamlessly, ensures rapid and uniform vulcanization of silicone insulation layers, greatly improves the temperature resistance grade, insulation performance and mechanical strength of cables, and is an essential core equipment for high-quality mass production of special silicone cables.
核心产品优势
多段独立温控系统 + 360° 热风循环结构，箱体内温差≤±1℃，无局部过硫 / 欠硫问题，保证线缆绝缘层硬度一致、弹性均匀、表面光滑无气泡，完美满足医疗、航天等高端领域严苛品质要求。
Multi-stage independent temperature control system + 360° hot air circulation structure, temperature difference inside the oven ≤±1℃, no local over-vulcanization/under-vulcanization problems, ensuring consistent hardness, uniform elasticity and smooth bubble-free surface of cable insulation layers, perfectly meeting the strict quality requirements of high-end fields such as medical treatment and aerospace.
采用远红外定向辐射加热 + 强制热风循环复合加热方式，热效率高达 90% 以上，比传统电热管硫化箱节能 30%-40%，大幅降低生产运营成本，同时升温速度提升 50%，开机即可快速进入生产状态。
Adopting far-infrared directional radiation heating + forced hot air circulation composite heating method, thermal efficiency is over 90%, saving 30%-40% energy compared with traditional electric heating tube vulcanization ovens, greatly reducing production and operation costs, while heating speed is increased by 50%, and production can be started quickly after power-on.
可与我司硅胶线缆挤出机实现全闭环同步联动，线速 0-80m/min 无极调节，自动匹配挤出速度，实现 "挤出 - 硫化 - 冷却" 全流程不间断生产，单条产线日产能最高可达 5 万米以上。
Can realize fully closed-loop synchronous linkage with our silicone cable extruder, stepless adjustment of line speed 0-80m/min, automatically match extrusion speed, realize uninterrupted production of the whole process of "extrusion-vulcanization-cooling", and the daily production capacity of a single production line can reach more than 50,000 meters.
10 寸工业触控屏，所有参数可视化设置与实时监控，支持硫化温度、线速、风量一键配方调用，异常自动报警并联动主机降速 / 停机，配备生产数据存储与导出功能，满足工厂数字化管理需求。
10-inch industrial touch screen, visual setting and real-time monitoring of all parameters, supports one-click formula calling of vulcanization temperature, line speed and air volume, automatic alarm for abnormalities and linkage with main engine speed reduction/shutdown, equipped with production data storage and export functions, meeting the digital management needs of factories.
全封闭隔热保温结构，外壳温度≤45℃，配备超温保护、过载保护、漏电保护、开门急停等多重安全防护；模块化设计便于维护保养，易损件更换便捷，设备使用寿命长达 10 年以上。
Fully enclosed heat insulation structure, shell temperature ≤45℃, equipped with multiple safety protections such as over-temperature protection, overload protection, leakage protection and door opening emergency stop; modular design facilitates maintenance, and wearing parts are easy to replace, with equipment service life of more than 10 years.
可根据客户产能需求定制不同长度、不同温度等级的硫化箱体，支持立式 / 卧式多种布局，可配套冷却段、印字段、牵引段组成完整硫化冷却单元，完美适配各类特种硅胶线缆生产工艺。
Can customize vulcanization boxes of different lengths and temperature grades according to customer production capacity needs, support vertical/horizontal various layouts, can be matched with cooling section, printing section and traction section to form a complete vulcanization cooling unit, perfectly adapting to various special silicone cable production processes
